GR86 (ZN8) Street and Light Circuit Version
Let’s enjoy circuit driving!
This aero device kit is a light downforce specification, but it significantly improves stability at high speeds and control in corners compared to standard vehicles. This product is for users who drive on the street or on the circuit.
Concept
The good points of the GR86 are the coolness of its simple and textured exterior, and the excitement of driving it thanks to its larger engine displacement than the previous model. With these points in mind, we set two themes and began development.
1. A design that brings out both style and functionality
To be more specific, here is what Vortex had to say about the design and functionality of the GR86:
- Compliant with safety standards
- Simple, timeless design with texture
- Moderate downforce for safety on the circuit
Our company has independently studied the function and design of aftermarket aero parts in response to user requests. We believe that we can utilize the experience we have gained in earnest up until now when considering aero parts that meet the safety standards of the GR86.
However, since users have different wants and preferences, we need to narrow the range a bit more. If something is liked by everyone, it cannot be liked strongly by everyone.
To be honest, I don’t know what will be the answer to what will receive strong support in this genre where many famous brands, including GR original parts, are competing to develop. Since I don’t know, my standard is “to make what I want.”
It was developed in search of the answer to the question, “What do I want?” – a simple, high-quality design that never gets old.
2. Why not make your circuit debut with the GR86?
This is something I would like to try myself, but I think there are still many users out there who would like to try racing on a circuit but feel it is too difficult.
Assuming you plan to practice on smaller courses first, and then race on faster tracks like the Suzuka Circuit, stability at high speeds is extremely important, and a well-balanced aero kit with wings is extremely useful for recovering from driving mistakes, especially as it softens the behavior when the rear skids.
Our goal is not to drive faster than anyone else, but to help you drive to the circuit and return safely.
Product
| Product name | Material | Standard installation time | Part number | ||
|---|---|---|---|---|---|
| ① | Front under spoiler | W.C. | 1.5h | 86FW | Clear coat |
| FRP | 1.5h | 86FF | Matte black paint | ||
| ② | Side under panel | W.C. | 2.0h | 86SW | Clear coat |
| FRP | 2.0h | 86SF | Matte black paint |
*The “WC” in the material name stands for wet carbon.
*As each item is handmade, delivery may take some time.
| Product | Material | Std instalL time | Part # | Finish | |
|---|---|---|---|---|---|
| ① | Front under spoiler | W.C. | 1.5h | 86FW | Clear coat |
| FRP | 1.5h | 86FF | Matte black paint | ||
| ② | Side under panel | W.C. | 2.0h | 86SW | Clear coat |
| FRP | 2.0h | 86SF | Matte black paint |
*The “WC” in the material name stands for wet carbon.
*As each item is handmade, delivery may take some time.
| Product name | Material | Standard installation time | Part number | Finish | |
|---|---|---|---|---|---|
| ③ | Rear under spoiler | W.C. | 1.5h | 86RW | Clear coating |
| FRP | 1.5h | 86RF | Matte black paint | ||
| ④ | Rear wing side mount | WC base FRP | 1.0h | 86WS | Wing body: Clear paint Base: Matte black paint |
| ⑤ | Rear wing center mount | Aluminum WC pedestal | 2.5h | 86WM | Wing body: Clear coat Base: Aluminum machined, anodized black |
| ⑥ | Rear wing Swan neck | Aluminum WC pedestal | 2.5h | 86WW | Wing body: Clear coat Base: Aluminum machined, anodized black |
*As each item is handmade, delivery may take some time.
| Product | Material | install time | Part # | Finish | |
|---|---|---|---|---|---|
| ③ | Rear under spoiler | W.C. | 1.5h | 86RW | Clear coating |
| FRP | 1.5h | 86RF | Matte black paint | ||
| ④ | Rear wing side mount | WC base FRP | 1.0h | 86WS | Wing body: Clear paint Base: Matte black paint |
| ⑤ | Rear wing center mount | Aluminum WC pedestal | 2.5h | 86WM | Wing body: Clear coat Base: Aluminum machined, anodized black |
| ⑥ | Rear wing Swan neck | Aluminum WC pedestal | 2.5h | 86WW | Wing body: Clear coat Base: Aluminum machined, anodized black |
*As each item is handmade, delivery may take some time.
Handling Precautions
- When aero parts are installed, the clearance between the road surface and the vehicle becomes smaller, making it easier for the car to come into contact with steps such as curbs and slopes.
- Rear wing reduces rear visibility
- If rainwater or other liquid remains on the top of the rear wing for a long period of time, it may become cloudy.
- Carbon products may turn yellow due to the effects of ultraviolet rays depending on storage conditions.
- The product warranty period is 1 year
- There is no expiry date for repairs and maintenance, but only for one-owner vehicles.
Carbon Molding Team
We are in charge of carbon molding, which is difficult to do by hand.
